RT7020GS RICHTEK IC GATE DRVR HALF-BRIDGE 8SOP
RT7020GS Images
RT7020GS Images
RT7020GS
  • Manufacturer: RICHTEK
  • Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 8-SOIC (0.154, 3.90mm Width)
  • Description: IC GATE DRVR HALF-BRIDGE 8SOP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
RT7020GS Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
RT7020GS Specifications:
  • MfrPart.: RT7020GS
  • Mfr: Richtek USA Inc.
  • Description: IC GATE DRVR HALF-BRIDGE 8SOP
  • Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • PartStatus: Obsolete
  • DrivenConfiguration: Half-Bridge
  • ChannelType: Independent
  • NumberofDrivers: 2
  • GateType: IGBT, N-Channel MOSFET
  • Voltage-Supply: 10V ~ 20V
  • LogicVoltage-VILVIH: 0.8V, 2.5V
  • Current-PeakOutput(SourceSink): 300mA, 600mA
  • InputType: Non-Inverting
  • HighSideVoltage-Max(Bootstrap): 600 V
  • Rise/FallTime(Typ): 70ns, 35ns
  • OperatingTemperature: -40°C ~ 125°C (TJ)
  • MountingType: Surface Mount
  • Package/Case: 8-SOIC (0.154, 3.90mm Width)
  • RT7020GS RICHTEK, IC GATE DRVR HALF-BRIDGE 8SOP, Integrated Circuits (ICs)~PMIC - Gate Drivers
