RT7021AGN RICHTEK IC GATE DRV HI-SIDE/LO-SIDE 8DIP
RT7021AGN Images
RT7021AGN Images
RT7021AGN
  • Manufacturer: RICHTEK
  • Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 8-DIP (0.300, 7.62mm)
  • Description: IC GATE DRV HI-SIDE/LO-SIDE 8DIP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
RT7021AGN Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
RT7021AGN Specifications:
  • MfrPart.: RT7021AGN
  • Mfr: Richtek USA Inc.
  • Description: IC GATE DRV HI-SIDE/LO-SIDE 8DIP
  • Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • DrivenConfiguration: High-Side or Low-Side
  • ChannelType: Independent
  • NumberofDrivers: 2
  • GateType: IGBT, N-Channel MOSFET
  • Voltage-Supply: 13V ~ 20V
  • LogicVoltage-VILVIH: 0.8V, 2.5V
  • Current-PeakOutput(SourceSink): 300mA, 600mA
  • InputType: Non-Inverting
  • HighSideVoltage-Max(Bootstrap): 600 V
  • Rise/FallTime(Typ): 70ns, 35ns
  • OperatingTemperature: -40°C ~ 125°C (TA)
  • MountingType: Through Hole
  • Package/Case: 8-DIP (0.300, 7.62mm)
  • RT7021AGN RICHTEK, IC GATE DRV HI-SIDE/LO-SIDE 8DIP, Integrated Circuits (ICs)~PMIC - Gate Drivers
