RT8560GQW RICHTEK IC LED DRIVER RGLTR DIM 20WQFN
RT8560GQW Images
RT8560GQW Images
RT8560GQW
  • Manufacturer: RICHTEK
  • Category: Integrated Circuits (ICs)~PMIC - LED Drivers Package/Case: 20-WFQFN Exposed Pad
  • Description: IC LED DRIVER RGLTR DIM 20WQFN
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
RT8560GQW Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
RT8560GQW Specifications:
  • MfrPart.: RT8560GQW
  • Mfr: Richtek USA Inc.
  • Description: IC LED DRIVER RGLTR DIM 20WQFN
  • Product Category: Integrated Circuits (ICs)~PMIC - LED Drivers
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • PartStatus: Discontinued at
  • Type: DC DC Regulator
  • Topology: Step-Up (Boost)
  • InternalSwitch(s): Yes
  • NumberofOutputs: 4
  • Voltage-Supply(Min): 7V
  • Voltage-Supply(Max): 40V
  • Voltage-Output: 60V
  • Current-Output/Channel: 30mA
  • Frequency: 1MHz
  • Dimming: Analog, PWM
  • Applications: Backlight
  • OperatingTemperature: -40°C ~ 85°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 20-WFQFN Exposed Pad
  • RT8560GQW RICHTEK, IC LED DRIVER RGLTR DIM 20WQFN, Integrated Circuits (ICs)~PMIC - LED Drivers
